Description
Cooling Capacity : 2638 W / 9,000 Btu/h.
Power Input (Cooling/Heating) : 830 W
Running Current ( Cooling/Heating) : 4.3 A
EER : 3.18 W/W / 10.84 Btu/h.W
Power Supply : 1 / 220~240 / 50 (Ø / V / Hz)
Air Flow Rate(Indoor,Max) : 9 ㎥/min
Air Flow Rate(Outdoor,Max) : 28 ㎥/min
Moisture Removal : 1.0 l/h.
Sound Level(Indoor,H/M/L/SL) 43 / 40 / 36 / – dB(A)±3
Sound Level( Outdoor,Max) : 50 dB(A)±3
Standard Pipe length : 5 m
Fan(Indoor) Type : Cross Flow Fan
Fan(Outdoor) Type : Fan,Propeller
Piping Connections(Liquid Side ) : 6.35 mm
Piping Connections(Gas Side) : 9.52 mm
Dimensions(Indoor (W*H*D)) : 835*270*175 mm
Dimensions(Outdoor (W*H*D)) : 720*500*270 mm
Net Weight(Indoor) : 7 kg
Net Weight(Outdoor) : 23.7 kg
Appearance
Indoor(Tool Code) : S4
Indoor(Remote) : G-INV
Indoor(Remote Controller Type) : Wirless LCD
Indoor(Grille Front Look) : N-Look
Indoor(Display) : LED
Outdoor(Tool Code) : UA3
Outdoor(Panel Type) : Steel
Outdoor(Condenser Type) : Cu(Gold Fin)
Feature & Function
Pre-Filter (in Front Grille) : Yes
* Vane Horizontal : Normal
Temperature Control : Thermistor
Natural Wind : Yes
Fan Speed : 3
Airflow Direction Control(up & Down) : Auto
Airflow Direction Control(left & right) : Manual
Setting Temperature Range(Cooling) : 18-30
Temperature Increment : 1
Self Diagnosis : Yes
Timer : 24hr Off
Soft Dry Operation : Yes
Restart Delay(minute) : 3
Jet Cool : Yes
Special Function
Gen Mode : Yes
Outdoor Operation Temp. (degree C) : 43
Compressor : Type Normal
